DESCRIPTION
The HIS15000 inverter voltage stabilizer is designed to protect against high and low mains voltage of electrical equipment with a power consumption of no more than 15kVA/13.5kW.
Installation and connection
HIS15000 is designed for mounting on a flat vertical surface (wall) using self-tapping screws, which are inserted into special holes on the back of the case. To connect the stabilizer to the network and power the load, terminal blocks are provided on the lower part of the case.
Instruct
To monitor basic operating parameters and emergencies, the unit is equipped with a panel with an LCD display, LED indicators and function buttons:
“Normal”- The indicator is steady on in normal mode and blinks when the automatic bypass mode is switched.
"Alarm" - lights up red when overheating or overload occurs (the corresponding information will appear on the LCD), as well as short circuits, internal product problems, disconnected input networks, low load resistance or insufficient supply voltage.
Cooling System
The HIS15000 is equipped with 6 fans. When the internal temperature of the device is lower than 50℃, the cooling fan is not used, and the device runs absolutely quietly. When the internal temperature exceeds 50℃, all 6 fans start
Product advantages
Input voltage range during operation 90/310V
A wider range of stable voltages
High precision stabilization
The device is designed with no moving components and is absolutely quiet during operation
Absolutely silent operation
The device is designed with no moving components and is absolutely quiet during operation
Transformerless circuit
The device has dual voltage conversion
Full digital control
Based on high performance digital signal processor
Conveniently display
Stabilizer operating mode, accident and network problem tips
High efficiency
Provides less power consumption
Immediate performance
Eliminates the risk of load damage due to power surges and expands the allowable load range of the link
The load during a network failure can be as long as 200ms
Ensure continuous load operation during short interruption of input voltage
Interference filtering
Effectively protects the load and input network from a wide range of high-frequency interference
Generator compatibility
The stabilizer will adjust the value and quality of the generator output signal to avoid unnecessary start-up
High overload capacity
Effectively cope with high starting currents including motor loads
Light weight and compact size
Combined with a modern design, it provides a comfortable placement in any space
Long Service Life
Advanced circuit solutions and modern electronic components are used
